Basic Info
Model No.: SEAMLESS STEEL PIPE
standard: bs, GB, ASTM, JIS, DIN, API
Section shape: Round
place of origin: China
application: Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, OIL PIPE, Chemical Fertilizer Pipe
Production Process: Cold Drawn
Certification: Bsi, ce, UL, API
Whether alloy: Is Alloy
Category: Welded Steel Pipe
Additional Info
Packaging: plywood cases, pallets, or as per your request.
Productivity: 100000Tons/year
Brand: GH
Transportation: Ocean,Land,Air
Place of Origin: CN
Supply Ability: 5000Tons/Week
Certificate: ISO9001:2008
HS Code: 730723
Port: Tianjin Port,Shanghai
Product Description
He Bei GuangHao Pipe Fittings Co .,LTD Specializing in the production of steel pipe and pipe fittings
Main production:Heat Preservation Anticorrosive Pipe，Seamless Pipe，ERW/HFW Steel Pipe，LSAW STEEL PIPE，Spiral Tube，Buttweld Steel Pipe Fittings,Industrial Flanges,Steel Pipes,Buttweld Elbows,Buttwel Tees,Forged fittings,etc.
Welcome to discuss
Forged Fittings/Buttweld Steel Pipe Fittings Type: Elbow, cross, street elbow, tee, coupling, half coupling, cap, plug, bushing, union, outlet, sage nipple, bull plug, reducer insert, pipe nipple etc.
Our main products include 8 series: Carbon steel seamless pipes for use in low and medium pressure boilers, petroleum casing tubes, ships, fluid conveyance, petroleum cracking, chemical fertilizer equipments, structures, and hollow pumping rods. We can produce seamless steel pipes from 12″ to D40″, thickness SCH30, SCH40, SCH80, SCH160 and so on, according to the standards such as \ASTM\API 5L\BS EN ISO,
(1)From 1/8″-4″, our pipes are cold drawning.
(2)From 4″-12″, our pipes are hot rolling.(stok available )
(3)Over 12″, our pipes are hot expending max 40'
| A53 Chemical components and mechanical propert | |||||||||||||||||||||||||||||||||||||||||||||||
| Standard | Trade mark | Chemical components | Mechanical property | ||||||||||||||||||||||||||||||||||||||||||||
| C | Si | Mn | P | S | Cu | Ni | Mo | Cr | V | Tensile Strength(Mpa) | Yield Strength (Mpa) | Elongation(%) | |||||||||||||||||||||||||||||||||||
| ASTM A53 | A | ≤0.25 | / | ≤0.95 | ≤0.05 | ≤0.06 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.40 | ≤0.08 | ≥ 330 | ≥ 205 | ≥ 29.5 | |||||||||||||||||||||||||||||||||
| B | ≤0.30 | / | ≤1.2 | ≤0.05 | ≤0.06 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.40 | ≤0.08 | ≥ 415 | ≥ 240 | ≥ 29.5 | ||||||||||||||||||||||||||||||||||
| A106 Chemical components and mechanical property | ||||||||||||||||||||||||||||||||||||||||||||||||
| Standard | Trade mark | Chemical components | Mechanical property | |||||||||||||||||||||||||||||||||||||||||||||
| C | Si | Mn | P | S | Cu | Ni | Mo | Cr | V |
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
||||||||||||||||||||||||||||||||||||
| ASTMA106 | B | ≤0.30 | ≥0.10 | 0.29~1.06 | ≤0.035 | ≤0.035 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.40 | ≤0.08 | ≥415 | ≥240 | ≥30 | ||||||||||||||||||||||||||||||||||
| C | ≤0.35 | ≥0.10 | 0.29~1.06 | ≤0.035 | ≤0.035 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.40 | ≤0.08 | ≥ 485 | ≥275 | ≥ 30 | |||||||||||||||||||||||||||||||||||
| API 5L Chemical components and mechanical property PSL1 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Class and Sort | Chemical components | Mechanical property | |||||||||||||||||||||||||||||||||||||||||||||||||||||
|
C (Max) |
Mn (Max) |
P (Max) |
S (Max) |
Tensile Strength( Min) | Yeild Strengh(Min) | ||||||||||||||||||||||||||||||||||||||||||||||||||
| psi | Mpa | psi | Mpa | ||||||||||||||||||||||||||||||||||||||||||||||||||||
| A25 | CLI | 0.21 | 0.6 | 0.03 | 0.03 | 45000 | 310 | 25000 | 172 | ||||||||||||||||||||||||||||||||||||||||||||||
| CLII | 0.21 | 0.6 | 0.03 | 0.03 | |||||||||||||||||||||||||||||||||||||||||||||||||||
| A | 0.22 | 0.9 | 0.03 | 0.03 | 48000 | 331 | 30000 | 207 | |||||||||||||||||||||||||||||||||||||||||||||||
| B | 0.28 | 1.2 | 0.03 | 0.03 | 60000 | 414 | 35000 | 214 | |||||||||||||||||||||||||||||||||||||||||||||||
| X42 | 0.28 | 1.3 | 0.03 | 0.03 | 60000 | 414 | 42000 | 290 | |||||||||||||||||||||||||||||||||||||||||||||||
| X46 | 0.28 | 1.4 | 0.03 | 0.03 | 63000 | 434 | 46000 | 317 | |||||||||||||||||||||||||||||||||||||||||||||||
| X52 | 0.28 | 1.4 | 0.03 | 0.03 | 66000 | 455 | 52000 | 359 | |||||||||||||||||||||||||||||||||||||||||||||||
| X56 | 0.28 | 1.4 | 0.03 | 0.03 | 71000 | 490 | 56000 | 386 | |||||||||||||||||||||||||||||||||||||||||||||||
| X60 | 0.28 | 1.4 | 0.03 | 0.03 | 75000 | 517 | 60000 | 414 | |||||||||||||||||||||||||||||||||||||||||||||||
| X65 | 0.28 | 1.4 | 0.03 | 0.03 | 77000 | 531 | 65000 | 448 | |||||||||||||||||||||||||||||||||||||||||||||||
| X70 | 0.28 | 1.4 | 0.03 | 0.03 | 82000 | 565 | |||||||||||||||||||||||||||||||||||||||||||||||||
| A192 Chemical components and mechanical property | ||||||||||||
| Chemical components | Mechanical property | |||||||||||
| Standard | Trademark | C | Si | Mn | P | S | Cu | Ni | Mo | Tensile Strength(Mpa) |
Yield Strength (Mpa) |
Elong ation (%) |
| ASTM A192 | A192 | 0.06-0.18 | ≤0.25 | 0.27-0.63 | 0 | 0.04 | / | / | / | ≥325 | ≥ 180 | |
Chemical components:
| Chemical components | Mechanical property | |||||||||||||||||||||||||||||||||||||||||||||||||||
| Standard | Trade mark | C | Si | Mn | P | S | Cr | Ni | Mo | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | ||||||||||||||||||||||||||||||||||||||||
| EN102016-2 | P235GH | ≤0.16 | ≤0.35 | ≤1.20 | ≤0.025 | ≤0.020 | 0.30 | / | ≤0.08 | 360-500 | ≥235 | ≥23 | ||||||||||||||||||||||||||||||||||||||||
| P265GH | ≤0.20 | ≤0.40 | ≤1.40 | ≤0.025 | ≤0.020 | 0.30 | / | ≤0.08 | 41 | |||||||||||||||||||||||||||||||||||||||||||
